Point-Of-Care® Bed Controls
36 Centrella® Smart+ Bed Instructions for Use (193587 REV 10)
Knee Up/Down
Foot Up/Down
Trendelenburg and Reverse Trendelenburg
The caregiver can raise or lower the knee section. The knee section has a maximum
travel of 30°.
To raise—press and hold the Knee Up control until the bed is at the desired position.
To lower—press and hold the Knee Down control until the bed is at the desired
position.
To put the bed in an auto contour position, press the Head Up and Knee Up controls at
the same time.
Caution—Make sure the drainage bags will not touch the floor. Remove them if necessary. Follow
facility protocol if the drainage bags touch the floor.
The Foley Position Limit can restrict how much the foot section can lower to reduce the likelihood of a
drainage bag touching the floor, see “Foley Position Limit” on page 72.
The caregiver can raise or lower the feet and lower extremities.
To raise—press and hold the Foot Up control to raise the foot section to the desired
position. The knees will first raise, then the feet/lower extremities will elevate so the
foot end of the bed is parallel to the floor.
To lower—for a chair-like position, press and hold the Knee Up control until you hear
a single beep. Then press and hold the Foot Down control to lower the foot section to
the desired position.
To level—to level the bed from the raised or lower position, press and hold Knee
Down until the bed stops and you hear a single beep.
Warning—Make sure the caregiver hands are kept away from the moving parts while operating the
bed.
You can use the Trendelenburg and Reverse Trendelenburg controls at any bed
height.
Trendelenburg—press and hold the Trendelenburg control until the foot end of
the bed raises relative to the head-end to the desired angle.
Caution—Make sure the drainage bags do not touch the floor. Remove them if necessary. Follow
facility protocol if the drainage bags touch the floor.
