Heart and Respiration Rate Monitoring System powered by EarlySense
92 Centrella® Smart+ Bed with Heart and Respiration Rate Monitoring System powered by EarlySense Instructions for Use
(193587 REV 10)
RESET HR AND RR DATA
• After approximately five minutes, the touchscreen will
default to the Status screen.
7. Reset the bed as follows:
c. Unplug the bed.
d. Press and hold the Lockout control (A) until you hear a beep
(approximately 20 seconds). This puts the bed in Service
mode.
e. Press and hold these controls at the same time until you hear a
beep: Foot Up (B), Foot Down (C), and Trendelenburg (D). The
bed should shut down within 5 seconds after you release the
controls.
f. Plug the bed in.
The HR and RR Monitoring System uses the same speaker as the Brake Not Set Alert for in-room alerts.
8. To check the HR and RR Monitoring System in-room alarm, do as follows:
a. Move the brake or steer pedal to the level position.
b. Listen for an alarm to sound.
To reset the HR and RR data, do the New Patient (Zero) scale procedure as follows:
These warnings apply to both zero the scale and weigh procedures. To help prevent injury and/or
equipment damage, obey these warnings:
• Warning—The scale is very sensitive. Make sure the bed is not touching anything that could
affect the patient weight (other beds or carts, headwall, miscellaneous drainage lines, etc.)
while the bed is in the zeroing or weighing process. Failure to do so could cause an
inaccurate weight reading.
• Warning—Always use the New Patient zero before a patient is admitted into the bed. Failure
to do so may keep old patient data in the bed and cause a risk to the new patient.
NOTES:
These notes apply to both zero the scale and weigh procedures:
• The scale will only work when the bed is connected to AC power.
• The equipment in the foot-end sockets will be included in the Zero and patient Weigh
processes.
• Everything on or attached to the articulating upper frame and siderails will be included in the
Zero and patient Weigh processes.
