Accessories
Centrella® Smart+ Bed Instructions for Use Manual (193587 REV 10) 121
3. Remove the pull pin from
the Patient Helper mount
on the head end of the bed.
4. Install the arm assembly
into the Patient Helper
mount. Make sure the arm
assembly is fully inserted in
the mount.
5. Insert the pull pin to hold
the Patient Helper arm
assembly in position.
6. Install the horizontal arm into the arm assembly, and insert the
pin to hold the horizontal arm in position.
7. Install the retainer on to the pin.
