10.1 Basic Specifications
______________________________________________________________________________________________
Current measurement
range
0.01 to 120.0 mA
Designated value Average value rectified effective value display ( digital )
Resolution 0.01 mA (2 mA / 8 mA ranges)
0.1 mA (32 mA range)
1 mA (120 mA range)
Accuracy 3%f.s. 20
µ
A ... for all ranges
( power waveform distortion is less than 5% )
Decision method Window comparator method ( digital setting )
Decision contents UPPER-FAIL : when measured current exceeds the upper limit setting
PASS : when measured current remains between the upper / lower limit
settings for set time
LOWER-FAIL : when the measured current is below the lower limit setting
Decision process Output to the display, beeper sound, signals to EXT I/O for each decision result
Setting range 0.1 to 120 mA (Upper limit value)
0.1 to 119 mA (Lower limit value)
Setting resolution 0.1 mA (0.1 - 9.9 mA)/ 1 mA (10 - 120 mA)
Current Detection Section
Decision Function
