10.1 Basic Specifications
______________________________________________________________________________________________
1
2
3
4
5
6
7
8
9
1
0
11
1
2
1
3
1
4
1
5
10.1.2 Insulation resistance test portion
Rated voltage 500 VDC/1000 VDC
No-load voltage 1 to 1.2 times the rated voltage.
Rated measured current 1 to 1.2 mA
Short circuit current 4 to 5 mA (500 V), 2 to 3 mA (1000 V)
Measured area and
accuracy
0.5 to 999 M
Ω
(500 V), 1 to 999 M
Ω
(1000 V)/ 4%rdg.,
1000 to 2000 M
Ω
/
8%rdg.
Measurement resolution 0.01 M
Ω
(0.50 M
Ω
- 19.99 M
Ω
), 0.1 M
Ω
(20.0 M
Ω
- 199.9 M
Ω
),
1M
Ω
(200 M
Ω
- 2000 M
Ω
)
Measured resistance
range
2M
Ω
,20M
Ω
, 200 M
Ω
, 2000 M
Ω
(500 V)
4M
Ω
,40M
Ω
, 400 M
Ω
, 2000 M
Ω
(1000 V)
Decision method Window comparator method ( digital setting )
Decision contents UPPER-FAIL : when measured current exceeds the upper limit setting
PASS : when measured current remains between the upper / lower limit
settings for set time
LOWER-FAIL : when the measured current is below the lower limit setting
Decision process Output to the display, beeper sound, signals to EXT I/O for each decision result
Setting range 0.2 to 2000 M
Ω
( both upper / lower limit value )
Setting resolution 0.01 M
Ω
(0.2 - 2.00 M
Ω
), 0.1 M
Ω
(2.10 - 20.0 M
Ω
), 1 M
Ω
(21.0 - 200 M
Ω
),
10 M
Ω
(210 - 2000 M
Ω
)
10.1.3 Timer Section
Setting ON Counts down time from start to preset time
Setting OFF Shows elapsed time from start
Setting range 0.5 s to 999 s
Setting resolution and
accuracy
0.1 s ( 0.5 s - 99.9 s ) 50 ms / 1 s ( 100 s - 999 s ) 0.5 s
Undetermined period 0.5 s
(Mask time until determination for insulation resistance test time starts.)
Test Voltage
Decision Function
