Hioki 3159 - 9615 H.V. Test Lead

6
_____________________________________________________________________________________________
1.2 Names and Functions of Parts
______________________________________________________________________________________________
1.2.4 9615 H.V. TEST LEAD
DANGER
The vinyl shield on the 9615 H.V. TEST LEAD alligator clip is not high
voltage insulated. Do not touch when high voltage is applied.
1
2
3
1
High-voltage side (red)
Low-voltage side (black)
1 Alligator clip
Connect to a test point on the tested object.
2 High-voltage output
plug
Connect to the HIGH terminal on the unit.
3 Low-voltage output
plug
Connect to the LOW terminal on the unit.
