Hioki 3159 - Connecting the External I;O Connector

11
_____________________________________________________________________________________________
2.2 Connecting the External I/O Connector
______________________________________________________________________________________________
1
2
3
4
5
6
7
8
9
1
0
11
1
2
1
3
1
4
A
Hook of the external I/O terminal
External I/O connector
NOTE
For the specifications of the external I/O connector, see Section 8.1.
If the optional "Interlock" function is set to "
1
: Set," set Pin 10 of the external I/O
terminal to "Lo" before starting a test. "
Err. 0
" will be indicated until "Lo" is set.
(
See Section 8.1.4
)
2.2 Connecting the External I/O Connector
Connect the external I/O connector before turning on the power. If the
external I/O connector is installed or removed following startup, malfunction
may result.
1. Insert the external I/O connector into the external I/O terminal.
2. Secure the external I/O connector using the hooks of the external I/O
terminal.
