Hioki 3159 - Hold Function

87
_____________________________________________________________________________________________
6.3 Hold Function
______________________________________________________________________________________________
1
2
3
4
5
6
7
8
9
1
0
11
1
2
1
3
1
4
A
0
:
Not held (Initial setting)
1
:
Held
6.3 Hold Function
Enable this function to hold the current state when testing is interrupted by
the
STOP
key.
To inactivate the hold function, press the STOP key. The unit reverts to the
READY state.
If the Hold function is not selected, the unit switches to the READY state
upon forced termination of the test.
1. Press
SHIFT
+
STOP
keys while in READY state to display the Optional
function setting screen.
2.
Use the
/
keys to move the flashing cursor to the position shown in the
figure.
3.
Use the / keys to set a value at the flashing cursor location.
4. To complete the optional settings, press
SHIFT + STOP keys. The unit
reverts to the READY state.
