Hioki 3159 - PASS Hold Function

85
_____________________________________________________________________________________________
6.1 PASS Hold Function
______________________________________________________________________________________________
1
2
3
4
5
6
7
8
9
1
0
11
1
2
1
3
1
4
A
0
:
Not held (Initial setting)
1
:
Held
6.1 PASS Hold Function
This function retains the value for the PASS state on test completion.
To inactivate the hold function, press the
STOP
key. The unit reverts to the
READY state.
If the PASS hold function is not selected, the test result is displayed for
about 0.3 second before the unit reverts to the READY state.
1. Press
SHIFT + STOP keys while in READY state to display the Optional
function setting screen.
2. Use the
/ keys to move the flashing cursor to the position shown in the
figure.
3. Use the
/ keys to set a value at the flashing cursor location.
4. To complete the optional settings, press
SHIFT + STOP keys. The unit
reverts to the READY state.
