Hioki 3159 - 4.3.1 Setting the Test Voltage Value

51
_____________________________________________________________________________________________
4.3 "SETTING " State
______________________________________________________________________________________________
4.3.1 Setting the Test Voltage Value
Test-voltage value:
1000 V
The test-voltage value can be set to 500 V or 1000 V.
1. If no flashing cursor is displayed in the insulation resistance mode
READY state, press either the
/ key to display the cursor in the
testvoltage value position.
2.
Change the test-voltage value using the
/
keys. The test-voltage value
can be set to 500 V or 1000 V.
3.
To finalize the test settings, press the STOP key. The settings are
confirmed and the unit returns to the READY state.
