Hioki 3159 - Chapter 7 Saving;Loading Preset Values; Saving Preset Values; Procedure for Saving Data

99
_____________________________________________________________________________________________
7.1 Saving Preset Values
______________________________________________________________________________________________
1
2
3
4
5
6
7
8
9
1
0
11
1
2
1
3
1
4
A
Withstand voltage
mode
Comparative voltage value, Upper limit value, Lower
limit value, Test time, Output voltage range
Insulation resistance
mode
Test voltage value, Upper limit value, Lower limit value,
Test time
NOTE
Optional function settings cannot be saved.
7.1.1 Procedure for Saving Data
Chapter 7
Saving/loading Preset Values
7.1 Saving Preset Values
The following describes a function used to save values set in the READY
state. Up to twenty parameters may be saved.
Up to 10 parameters may be saved in the each mode, such as the withstand
voltage and insulation resistance modes. To retrieve saved data, follow the
procedures described in Section 7.2.
The following parameters can be saved:
You must make the settings first before they can be saved. Parameters
cannot be changed on the Save screen.
(1) Selecting a test mode
Select the test mode where you want to save settings for the W or I key.
(2) Displaying the save screen
With the target preset value displayed in the READY state, press SHIFT +
keys to shift to the save screen.
In the save screen, the saved data for the file number replaces the target
value displayed in the READY state.
The first saved data displayed is the last data from the previous save screen.
