5.1 Withstand Voltage Mode Display
______________________________________________________________________________________________
Withstand voltage mode READY state
Insulation resistance mode READY state
The unit is ready for starting a test. The
READY
lamp is turned on.
W I (Withstand Voltage test Insulation Resistance test) mode: the unit is in the READY
state for withstand voltage testing.
I W (Insulation Resistance test Withstand voltage test) mode: the unit is in the READY
state for insulation resistance testing.
Press the
START
key while in the READY state.
Press
SHIFT
+
STOP
keys to display the Optional Function Setting screen.
Key-lock Function can be used. (See Section 5.2.1)
｢READY 状態｣
READY
state
Setting the optional functions allows testing under various conditions.
(See Chapter 6)
To make test settings, withstand voltage mode must be in the SETTING state.
For details on settings, see Chapter 3, "Withstand Voltage Mode Testing Method."
Make sure you set a test time.
｢READY 状態｣
Setting optional functions
W I
/
I W
key
SHIFT
+
STOP
key
To make test settings, insulation resistance mode must be in the SETTING state.
For details on settings, see Chapter 4, "Insulation Resistance Mode Testing Method."
Make sure you set a test time.
