4.5 PASS or FAIL Determination
______________________________________________________________________________________________
4.5.1 "PASS" State
WARNING
Even when a test has been terminated, there may still be voltage in the
output-voltage terminal. Before touching the output-voltage terminal,
H.V. TEST LEAD, or tested object, confirm the following items.
(1) The analog voltmeter reads 0 kV.
(2) The
DANGER
lamp is OFF.
(3) The
READY
lamp is lit (it is off in the Double Action mode).
4.5 PASS or FAIL Determination
When the preset test time has elapsed, and the measured resistance value
exceeds the lower-limit value, or falls below the upper-limit value, the unit
switches to the PASS state. The unit switches to the PASS state and
immediately stops outputting a voltage.
If the test time has not been set, PASS screening is not performed. To the
test, press the STOP key, which will forcibly terminate the test.
Optional Functions
The PASS state is held using the PASS Hold function. (See Section 6.1)
If the test time is set, the test can be forcibly terminated when the
measured resistance value enters the PASS range before the preset time
has elapsed. This is convenient when testing objects that contains capacity
loads. (See Section 6.11)
