Hioki 3159 - Page 73

61
_____________________________________________________________________________________________
4.5 PASS or FAIL Determination
______________________________________________________________________________________________
Flow of PASS determination
1.
Press the START key to start a test.
2.
A voltage is output until the test time elapses and the resistance is
measured.
3.
When the preset test time has elapsed and the measured resistance value
is within the upper- and lower-limit values, the unit stops outputting a
voltage and switches to the PASS state.
PASS
lights up in the PASS state.
