3.5 PASS or FAIL Determination
______________________________________________________________________________________________





NOTE
If the optional "Voltage Comparator Position" function is set to "
1
:Endoftest
time", since the unit shifts to the TEST state whenever voltage is output,
TEST
does
not flash before the output-voltage value reaches the comparative-voltage value
ran
g
e.
Flow of PASS determination
1.
Press the START key to start a test.
2.
If a comparative-voltage value has been set,
TEST
flickers until the output
voltage switches to the comparative-voltage range. When the output
voltage switches to that range,
TEST
remains lit and the reduction timer
begins counting down the test time.
3. A voltage is output until the test time elapses. (If the measured-current
value deviates from the upper- and lower-limit values, the unit switches to
the FAIL state.
4.
When the preset test time has elapsed, the unit stops outputting a voltage
and switches to the PASS state.
PASS
lights up in the PASS state.
