8.3.3 Specific Commands for Output Settings
────────────────────────────────────────────────────
Syntax
:OSET:TRACking <chno>,<item>
<chno> Channels to be set
= OFF
= CH1_2 (Simultaneous settings for
channels 1 and 2)
= CH1_3 (Simultaneous settings for
channels 1 to 3)
= CH1_4 (Simultaneous settings for
channels 1 to 4)
<item> Item to be set simltaneously.
= WAVE (The waveforms are set)
= FREQuency (The frequency is set)
= AMPLitude (The amplitude is set)
= FILTer (The filter is set)
= DUTY (The duty is set)
Example
Transmission
:OSET:TRAC CH1 2,AMPL
The amplitude of channels 1 and 2 is
set simultaneously.
Syntax
:OSET:SWEep <ch>,<ON/OFF>
<ch> Channel number
= 1 to 4 (1 to 2 for the 7075-01)
<ON/OFF>
ON: Enables the sweep function.
OFF: Disables the sweep function.
Example
Transmission
:OSET:SWE 1,ON
Enables the sweep function for channe
l
1.
Function
Perform simultaneous settings.
Note
CH1_3/CH1_4 cannot be specified on
the 7075-01.
Errors
(Command error)
When characters are specified other
than those at the left.
(Execution error)
When <chno> is set to CH1_3/
CH1_4 with using the 7075-01
When sweep is on for the channel to
be set simultaneously.
When the waveforms are set
simltaneously during RUN is active.
Function
Enables or disables the sweep function.
Note
Upon normal finish, EOSL in Event
Status Register 0 is set.
Errors
(Command error)
When the setting data contains
characters other than ON or OFF.
(Execution error)
If a sweep setting, such as editing in
the sweep table, has not be done at
least once.
When RUN is active.
:OSET:TRACking
Perform simultaneous settings.
:OSET:SWEep
Sets the sweep function.
