97
────────────────────────────────────────────────────
8.3.3 Specific Commands for Output Settings
────────────────────────────────────────────────────
Syntax
:OSET:WAVE <ch>,<wave>
<ch> Channel number
= 1 to 4 (1 to 2 for the 7075-01)
<wave>
=SINe Sinewaveform
= SQUare Square waveform
= PULSe Pulse waveform
= TRIangle Triangle waveform
= RAMP1 Ramp-up
= RAMP2 Ramp-down
= NOISe Noize
= DC DC
= AWG Arbitrary waveform
Example
Transmission
:OSET:WAVE 1,SIN
Sets the waveform for channel 1 to
SIN wave.
Syntax
:OSET:WAVE? <ch>
<ch> Channel number
= 1 to 4 (1 to 2 for the 7075-01)
Response
syntax
(Header ON)
:OSET:WAVE <ch>,<wave>
(Header OFF)
<ch>,<wave>
Example
Transmission
Response
:OSET:WAVE? 1
(Header ON)
:OSET:WAVE 1,SINE
(Header OFF)
1,SINE
Function
Selects a basic waveform.
Notes
Frequency, amplitude and offset
settings may be limited depending on
the specified waveform.
When an arbitrary waveform is
specified, the waveform is the
previously specified arbitrary
waveform. If no arbitrary waveform
has been previously specified, an
arbitrary waveform cannot be specified
here.
Upon normal finish, EOWL in Event
Status Register 0 is set.
Errors
(Command error)
When characters are specified other
than those at the left.
(Execution error)
When sweep is on
When arbitrary waveform is specified
without an arbitrary waveform having
been previously specified.
When RUN is active.
Function
Returns the waveform for the specified
channel as a character data.
Note
With this query, if any error occurs, no
response message is produced.
Error
(Execution error)
When sweep is on
:OSET:WAVE
Selects a basic waveform.
:OSET:WAVE?
Queries the basic waveform
