98
────────────────────────────────────────────────────
8.3.3 Specific Commands for Output Settings
────────────────────────────────────────────────────
Syntax
:OSET:AWG <ch>, "<name>"
<ch> Channel number
= 1 to 4 (1 to 2 for the 7075-01)
"<name>" Name of the arbitrary
waveform
Example
Transmission
:OSET:AWG 1,'WAVE(1)'
Sets the name of the arbitrary
waveform for channel 1 to WAVE(1).
Syntax
:OSET:AWG? <ch>
<ch> Channel number
= 1 to 4 (1 to 2 for the 7075-01)
Response
syntax
(Header ON)
:OSET:AWG <ch>,"<name>"
(Header OFF)
<ch>,"<name>"
Example
Transmission
Response
:OSET:AWG? 1
(Header ON)
:OSET:AWG 1,"WAVE(1) "
(Header OFF)
1,"WAVE(1) "
Function
Sets the name of the arbitrary
waveform.
Notes
The waveform name must be
surrounded by single (' ') or double ("
") quotes.
Waveform names are case sensitive.
Although an arbitrary waveform can
be given the name of a basic
waveform, the arbitrary waveform will
not be output when selected.
Upon normal finish, EOWL in Event
Status Register 0 is set.
Errors
(Command error)
When a waveform name is not
surrounded by single (' ') or double
(" ") quotes
(Execution error)
When the specified arbitrary waveform
is not present
When RUN is active.
Function
Returns the name of the arbitrary
waveform waveform name for the
specified channel as a character data
("name")
Notes
With this query, if any error occurs,
no response message is produced.
Waveform names are displayed as up
to eight characters, padded on the
right with spaces.
Error
(Execution error)
If the name of the arbitrary waveform
is not specified
:OSET:AWG
Sets the name of the arbitrary waveform.
:OSET:AWG?
Queires the name of the arbitrary waveform.
