99
────────────────────────────────────────────────────
8.3.3 Specific Commands for Output Settings
────────────────────────────────────────────────────
Syntax
:OSET:AWG:SIZE? "<name>"
"<name>" Name of the arbitrary
waveform
Response
syntax
(Header ON)
:OSET:AWG:SIZE "<name>",<size>
(Header OFF)
"<name>",<size>
Example
Transmission
Response
:OSET:AWG:SIZE? 'WAVE(1)'
(Header ON)
:OSET:AWG:SIZE "WAVE(1) ",1000
(Header OFF)
"WAVE(1) ",1000
Syntax
:OSET:AWG:NUMBer?
Response
syntax
(Header ON)
:OSET:AWG:NUMBER <NR1>
(Header OFF)
<NR1>
Example
Transmission
Response
:OSET:AWG:NUMB?
(Header ON)
:OSET:AWG:NUMBER 3
(Header OFF)
3
Function
Returns the size of the specified
arbitrary waveform as NR1 numerical
data.
Notes
With this query, if any error occurs,
no response message is produced.
The waveform name must be
surrounded by single (' ') or double
(" ") quotes.
Waveform names are case sensitive.
Waveform names of response syntax
are displayed as up to eight characters,
padded on the right with spaces.
Errors
(Command error)
When a waveform name is not
surrounded by single (' ') or double
(" ") quotes.
(Execution error)
When the specified arbitrary waveform
is not present.
When the waveform name is not
specified.
Function
Returns the number of arbitrary
waveforms as NR1 numerical data.
Note
With this query, if any error occurs, no
response message is produced.
:OSET:AWG:SIZE?
Queries the size of the specified arbitrary waveform.
:OSET:AWG:NUMBer?
Queries the number of arbitrary waveform.
