100
────────────────────────────────────────────────────
8.3.3 Specific Commands for Output Settings
────────────────────────────────────────────────────
Syntax
:OSET:AWG:LIST?
Response
syntax
(Header ON)
:OSET:AWG:LIST
"<name1>","<name2>",...
(Header OFF)
"<name1>","<name2>",...
Example
Transmission
Response
:OSET:AWG:LIST?
(Header ON)
:OSET:AWG:LIST "WAVE(1) ",
"WAVE(2) ","WAVE(3) "
(Header OFF)
"WAVE(1) " ,"WAVE(2) ","WAVE(3) "
Syntax
:OSET:AWG:CLEar
Example
Transmission
:OSET:AWG:CLE
Syntax
:OUT <ch>,<ON/OFF>
<ch> Channel number
= 1 to 4 (1 to 2 for the 7075-01)
<ON/OFF>
ON: Enables the output relay.
OFF: Disables the output relay.
Example
Transmission
:OUT 1,ON
Enables the output relay for channel 1.
Function
Returns a list of arbitrary waveform
names as a series of strings "<name1>,
<name2>, ...."
Notes
With this query, if any error occurs,
no response message is produced.
Waveform names of response syntax
are displayed as up to eight characters,
padded on the right with spaces.
Error
(Execution error)
No waveform is present
Function
Deletes all arbitrary waveforms.
Notes
If an arbitrary waveform is assigned to
a channel, it cannot be deleted.
Regardless of sweep on/off setting, if
an arbitrary waveform is assigned to a
channel, it cannot be deleted.
Errors
(Execution error)
If an arbitrary waveform is assigned to
a channel
Regardless of sweep on/off setting, if
an arbitrary waveform is assigned to a
channel
Function
Enables and disables the output relay.
Error
(Command error)
When characters are specified other
than those at the left.
:OSET:AWG:LIST?
Queries the list of arbitrary waveform names.
:OSET:AWG:CLEar
Deletes all arbitrary waveforms.
:OUT
Sets the output relay.
