132
────────────────────────────────────────────────────
10.2 Function Specifications
────────────────────────────────────────────────────
Amplitude resolution
16-bit equivalent (64000 count)
Waveform memory capacity
128000 words/channel
Filter
Second-order LPF, 50 Hz to 1 MHz (14 steps with 1-, 2- and 5-multiple
system series)
Waveform input method
Loadable from floppy disk, GP-IB or RS-232C (can be downloaded
directly from Memory HiCorder)
DC output accuracy
Within (2% of setting value + 25 mVrms)
DC output stability
Within (DC output accuracy X 0.1)/
Amplitude accuracy
Within (2% of setting value + 20 mVrms) at size 10000, sine wave of
10 MHz clock
Delay
Settable within 128000 range in 1-clock units
Clock for arbitrary waveform
Number of channels: 4 channels max. (same as the number of waveform
output channels)
Frequency range:0 to 10 MHz (resolution 10 mHz)
Frequency accuracy: Within
(50 ppm of setting value + 50 μHz)
Jitter: Within the larger of 800 ps-rms or 0.05% of set period
Number of loops
1 to 65535 or
Sweep waveform
Function generator, arbitrary waveform
Sweep form
Linear (inside of element)
Sweep object
Function generator:
Frequency, amplitude, offset, duty (pulse wave only)
(frequency, amplitude and offset can be swept simultaneously )
Arbitrary waveform:
Frequency, amplitude, offset
Sequence function
Sequence length
Loop repetitions
Trigger
Total number of loops
Outputs the sweep elements combined.
128 elements max
Loop: outputs the element or group the specified number of times
Hold: continually outputs the last data element
1024 times max or
Cancel infinite loop and hold to move to the next element
Maximum 65535 times or
Monitor function
Monitor display
Monitor channel
Display update interval
The number of loops to repeat sweep
Only the channel displayed can be monitored. The display channel can
be switched during output.
Approx. 200 ms
Maker function
Line number marker
Output value marker
Output for specified element number.
Settings: Specify sequence element number
Number of elements that can be set: Setting is possible for all elements
(multiple element setting is possible).
Output when sweep output data lies between two values set.
Settings: Element number, number of element loops, output values (x2)
Number of output values that can be set: Only one pair per sequence.
Arbitrary waveform generator function (Accuracy measured in the 10 V range)
Sweep Function
