10.2 Function Specifications
────────────────────────────────────────────────────
TRIG IN
TRIG OUT
MARKER OUT
Logic level 0 to 5 V (channels 1 to 4 independently controllable)
RUN/STOP IN
RUN/STOP OUT
SYNC.CLK IN
SYNC.CLK OUT
MASTER CLK IN
MASTER CLK OUT
Logic level 0 to 5 V
Changing the setting format
Frequency - Period
Amplitude - Upper limit value
Offset - Lower limit value
Selecting units
Hz - r/min
Vpeak - Vrms
Save output conditions
Waveform conditions and waveform at power off are retained by
memory backup
Synchronized operation
4 units max (16 channels)
Waveforms stored in internal
memory
8
Input/Output Controls
Others
