82
────────────────────────────────────────────────────
8.3.1 Standard Command
────────────────────────────────────────────────────
Syntax
*SRE <NR1>
<NR1> = 0 to 255
Example
Transmission
*SRE 33
Bits 0 and 5 of SRER are set to 1.
Syntax
*SRE?
Response
syntax
(Header ON) (Header OFF)
*SRE <0-255> <0-255>
Example
Transmission
Response
(Header ON) (Header OFF)
*SRE?
33
Syntax
*
STB?
Response
syntax
(Header ON/OFF)
*STB <NR1> <NR1>
Example
Transmission
Response
(Header ON) (Header OFF)
*STB?
32
An event occurred at Status Register
(ESB) bit 5.
Function
Loads the effective format of the Status
Byte Register (STB) into the Service
Request Enable Register (SRER).
Decimals are rounded off.
128 64 32 16 8 4 2 1
bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0
Unused
- ESB MAV - - - ESB0
Notes
When the power is turned on, the data is
reinitialized to 0.
The setting of unused bit (bit 7, 3, 2,
and 1) and the setting of bit 6 are
ignored.
Error
(Command error)
When <NR1> was not in NRf format.
Function
Returns the value of the service request
enable register (SRER) set by the *SRE
command as a numerical data value in
NR1 format (0 to 255)
Note
With this query, if any error occurs, no
response message is produced.
Function
Returns the set contents of the status byte
register (STB) as a numerical data value
in NR1 format (0 to 255).
128 64 32 16 8 4 2 1
bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0
Unused
MSS ESB MAV
Unused Unused Unused
ESB0
Notes
Bit 6 is the MSS bit.
Even if service requests are cleared by
serial polling, the MSS bit is not cleared.
*SRE (GP-IB only)
Sets the service request enable register (SRER).
*SRE? (GP-IB only)
Queries the service request enable register (SRER).
*
STB? (GP-IB only)
Queries the status byte register.
