249
Conguring and Establishing a LAN Connection
Troubleshooting LAN connections
Are the cables connected properly?
• There may be a faulty contact in the connector. Disconnect and reconnect the cable.
• The LINK LED on the instrument’s LAN connector will light up once a connection has been
established.
Has the computer’s IP address been set properly?
• Check the IP address, subnet mask, and gateway address set for the computer’s network
interface.
1
Press the Windows key and the R key at the same time.
The [Run...] dialog box will be displayed.
2
Enter CMD and press the ENTER key.
The [CMD.exe] window will open.
3
When the cursor starts ashing, enter ipcong/all and press the ENTER key.
Can the instrument and computer communicate?
• If the instrument and computer’s IP addresses have been set properly, you can check whether
the computer can communicate with the instrument using the ping protocol.
1
Press the Windows key and the R key at the same time.
The [Run...] dialog box will be displayed.
2
Enter CMD and press the ENTER key.
The [CMD.exe] window will open.
3
Once the cursor starts ashing, enter ping XXX.XXX.X.X (using the IP address you
wish to verify) and press the ENTER key.
If an IP address can be obtained from the hostname using DNS, you may also enter the
hostname.
For example, if the instrument’s IP address is 192.168.1.2, enter ping 192.168.1.2.
4
Check the computer's display.
Output like the following indicates normal connectivity. The expression time indicates the
amount of time required for the operation to complete.
Pinging 192.168.1.2 with 32 bytes of data:
Reply from 192.168.1.2: bytes=32 time<10ms TTL=32
Reply from 192.168.1.2: bytes=32 time<10ms TTL=32
Reply from 192.168.1.2: bytes=32 time<10ms TTL=32
Reply from 192.168.1.2: bytes=32 time=1ms TTL=32
Output such as the following indicates a connectivity issue. Check the cable connection.
Pinging 192.168.1.2 with 32 bytes of data:
Reply from 192.168.1.2: Host is down.
Reply from 192.168.1.2: Host is down.
Reply from 192.168.1.2: Host is down.
Reply from 192.168.1.2: Host is down.
Communicating with a Computer (PC)
