2 - 12
Alarm
Control
No.
Alarm Category
Sub-
code
Level Description Remedy
2891 to
2894
DC POWER 71 1 STOP 15 V DC power supply is
abnormal.
Replace the ±15 V
power supply
module.
71 2 STOP -15 V DC power supply is
abnormal.
Same as above
71 3 WARNING 12 V lamp power supply is
abnormal.
Replace the 12 V
power supply.
71 4 STOP 5 V power supply is abnormal.
71 11 E.STOP 24 V DC
2911 FUSE 72 1 E.STOP AC fuse has blown. Replace the F3
fuse.
2921 POWER
FAIL
73 1 WARNING Power supply to the
instrument is interrupted
Check power
supply.
2941 to
2973
MOTOR
CONTROL-
LER
75 1 to 18 STOP Data cannot be written into
the motor controller.
Replace ECPU230.
2991 to
3023
MOTOR
TIMEOUT
76 1 to 18 E.STOP Motor operation was
abnormal. Error has been
detected in the time-out check
of motor controller.
Sub-code Motor
1 Reaction disk
2 Sample disk
3 Reagent disk
4 Rinsing mechanism
up/down
5 Sample arm
up/down
6 Sample arm
rotation
7 Reagent arm
up/down
8 Reagent arm
rotation
9 Stirrer up/down
10 Stirrer rotation
11 ISE sipper up/down
12 (Unassigned)
13 Serum syringe
14 Reagent syringe
15 ISE syringe
16 (Unassigned)
17 GMCNT
18 (Unassigned)
(1) Replace
ECPU230.
(2) Check the
mechanism
which caused
alarm.
(cont’d)
5 V for other than
CPU board
To Next Page
