Troubleshooting the controller

Procedure

1. In the Alert Detail window of the maintenance utility, click Close.

2. In the left pane, click Controller Chassis.

Maintenance Utility window for CBSS or CBSL

Maintenance Utility window for CBLM or CBLH

Troubleshooting the controller 181

Service Guide for VSP Gx00 and VSP Fx00 Models
