Table 9-3: Programming Options for 5815XL Modules
Type
Selection
Function Latching Option Comments
UNUSED Select for SLC points that are unused.
DETECTOR
PHOTO Spot photoelectric detectors.
ION Spot ionization detector.
HEAT Spot heat detector.
PHOTO DUCT Duct photoelectric detector.
ION DUCT Duct Ion detector.
ACCLIMATE Acclimate photoelectric detector.
HEAT HT High temperature heat detector.
PHOTO-HEAT Photoelectric detector with heat sensor.
BEAM Beam smoke detector.
2-WIRE SMOKE 2-wire smoke detector.
SUP DET
PHOTO Latching
Non Latching
Use this option when you want a detector to indicate a supervisory
alarm.
ION
HEAT
PHOTO DUCT
ION DUCT
ACCLIMATE
HEAT HT
PHOTO-HEAT
BEAM
CO SMOKE
DETECTOR
CO ALRM / FIRE
ALRM
CO ALRM / FIRE
SUPR
CO SUPR / FIRE
ALRM
CO SUPR / FIRE
SUPR
Latching
Non Latching
Supervisory switches can be latching or non-latching.
