151430-L8 Testing and Troubleshooting
13-4
5. Enter up to 8 SLC addresses for the devices you wish to locate.
The LEDs on the selected devices will start flashing.
6. Press the left arrow to exit SLC Multiple Device Locator.
Note: Once you exit, the system will resume normal operation.
13.5.3 I/O Point Control
This feature allows you to toggle any output on or off and trip any input device. This can be useful to test a
point’s output mapping.
Follow these steps to control an I/O point:
1. Select 2 (Point Functions) from the Main Menu.
2. Select 6 (I/O Point Control).
3. Select the module the point is on.
4. Make any selections specific to the module selected in the previous step.
5. Use the Up or Down arrow to select the point you wish to test.
6. Press ENTER to generate an alarm for an input point or activate an output point.
7. To exit press the left arrow.
13.5.4 Earth Fault Resistance
Table 13-1 lists the earth fault resistance detection for each applicable terminal on the FACP.
Table 13-1: Earth Fault Resistance Values by Terminal
Function
Terminal Label Low Biased High Biased
(Values in Ohms)
High
Trip
High
Restore
Low
Trip
Low
Restore
Flexput™
Notification
Circuits
X I/O 8 – – 0 0
O00––
X I/O 7 – – 0 0
O00––
X I/O 6 - - 0 0
O00--
X I/O 5 - - 0 0
O00--
X I/O 4 - - 0 0
O00--
X I/O 3 - - 0 0
O00--
X I/O 2 - - 0 0
O00--
X I/O 1 - - 0 0
O00--
SBUS
Communication
B SBUS1 OUT - - 0 0
A--00
SBUS Power + 0 0 - -
---00
