Model IFP-2000/ECS Installation Manual 151430-L8
10-3
10.3.2 Using the Menus
10.4 Basic Operation
10.4.1 Setting Time and Date
1. From the Main Menu, select 4 for Set Date & Time.
2. Make changes in the fields on the screen. Use right arrow to move through the fields. Use the Up or Down
arrow to select options in the fields.
3. When the date and time are correct, press ENTER.
10.4.2 Disable / Enable a Point
1. From the Main Menu, select 2 for Point Functions.
2. Select 1 for Disable/Enable Point.
10.4.2.1 Disable / Enable NACs by Template
1. Press 1 for Disable NACs by Template, press 2 to Enable NACs by Template.
2. Use
the Up or Down arrow to move through the list of templates. Press ENTER to select the current template.
10.4.2.2 Disable / Enable NACs by Group
1. Press 3 to Disable NACs by Group, press 4 to Enable NACs by Group.
2. Use
the Up or Down arrow to move through the list of groups. Press ENTER to select the group highlighted.
10.4.2.3 Disable / Enable Zone Points
1. Press 5 to Disable Zone Points, press 6 to Enable Zone Points.
2. Use
the Up or Down arrow to move through the list of zones. Press ENTER to select the zone highlighted.
10.4.2.4 Disable / Enable Point
1. From the Main Menu, select 2 for Point Functions.
2. Press 7 to Disable /Enable Point.
3. Choose Module.
4. Use
the Up or Down arrow to choose point and press ENTER.
5. Press the right arrow to disable or enable point.
10.4.2.5 Inhibit Output Group
Inhibiting an output group prevents the group from being utilized by system mapping. While inhibited no event
in the system can activate the output group.
To move through the menus: Use the Up or Down arrow to move through the options in a menu.
To select an option: Enter the number of the option.
–OR–
Press ENTER if the option has the = symbol next to it.
Exit Menu Left arrow
To Next Page
