Model IFP-2000/ECS Installation Manual 151430-L8
9-21
8. Select Report Time Interval by pressing the Up or Down arrow, then press ENTER. Time Interval selections
are 24hr, 12hr, 6hr and 4 hr.
9.6.2 Phone Lines
To access the phone lines screen:
1. Enter the installer code. The panel will automatically go to the main menu.
2. Select 7 for Panel Programming.
3. Select 5 for System Options.
4. Select 1 for the phone Lines.
5. Select Phone Line to be edited (1 or 2) by pressing the Up or Down arrow, then press ENTER.
Figure 9-10 Phone Lines Editing Screen
9.6.2.1 Dialing Prefix
Enter up to 9 characters to be used for such things as PBX dial-out codes, a pause, and so on. The following
special characters are available:
Use the number buttons on the annunciator or the up- and down-arrow keys to select special characters. Special
characters begin displaying after “9”.
6. Enter a dialing prefix (if needed), then press ENTER. Or Press the right arrow to bypass the dialing prefix
option.
9.6.2.2 Number of Answer Rings
This option is used in conjunction with SKSS-2. Use this option to determine the number of rings before the
panel answers a call from the computer. Range is 00-15 rings. This option is factory-programmed as 06 rings,
which should be compatible for most installations where the answering machine bypass feature is used. You may
# Pound (or number) key on the telephone
* Star key on the telephone
, Comma (character for 2-second pause)
