Model IFP-2000/ECS Installation Manual 151430-L8
10-1
Section 10
System Operation
Operation of the control panel is user friendly. Menus guide you step-by-step through operations. This section of
the manual is an overview of the operation menus. Please read this entire section carefully before operating the
panel.
Note: See Section 6.3 for information on how to modify user access code profiles.
10.1 User and Installer Default Codes
Installer Code (factory-programmed as 123456).
Multi-site Installer Code (factory-programmed as 654321).
10.2 Annunciator Description
Figure 10-1 shows the annunciator that is part of the control panel board assembly.
Figure 10-1 Control Panel Annunciator
10.2.1 LCD Display
The control panel LCD displays system messages, annunciates alarms, supervisories and troubles, provides
status information, and prompts for input. These messages can be up to 160 characters, displaying over four lines
