Model IFP-2000/ECS Installation Manual 151430-L8
9-13
SWITCH
(cont.)
STATUS POINT
ECS INPUT Latching User also has ECS Event Number 1-8 option for ECS INPUT.
Only available when an ECS-VCM is installed in the system.
Non Latching
ECS TAMPER Latching
Non Latching
ECS SUPER-
VISORY
Latching
Non Latching
CO DETECT SW CO Detector Switch
NOTIF
OUTPUT PT Select Group Output point, a general use notification type. Use for driving
standard notification appliances.
AUX CONST Use constant power for applications that require a constant auxiliary
power source. Power is always present at constant circuits.
AUX RESET Use for auxiliary power, resettable applications. See Section
4.12.5.3 for a description of how this option operates.
AUX DOOR Use for auxiliary power, door holder applications. For example, if
you were using an auxiliary power supply for door holders, you
would use this option. See Section 4.12.5.1 for a description of how
this option operates.
RELAY
OUTPUT PT Select Group Output point, a general use relay type. Use for applications requiring
a relay, such as fan shutdown, elevator recall, and so on.
AUX RESET Use for auxiliary power, resettable applications. See Section
4.12.5.3 for a description of how this option operates.
AUX DOOR Use for auxiliary power, door holder applications. For example, if
you were using an auxiliary power supply for door holders, you
would use this option. See Section 4.12.5.1 for a description of how
this option operates.
SLC LED
LED NUMBER 01-80 For use with SD devices only. 80 sub addresses on LED.
LED FUNCTION Unused
NOTIF Notification can have group number.
2-WIRE
DETECTOR
MODULE
For use with conventional 2-wire detectors.
Table 9-3: Programming Options for 5815XL Modules
Type
Selection
Function Latching Option Comments
To Next Page
