151430-L8 Emergency Communication System Operation
11-14
8. Release the PTT button on the microphone to save your message. The Select Key green LED for this loca-
tion will turn on.
9. To playback the recorded message, press the Select Key 1-15 that was just recorded to.
10. If you are not satisfied with the recorded message, erase it (see Section 11.8.3) and then repeat steps 1
through 7.
Recording with Microphone Example:
User wants to record a message to message slot 5 via the microphone.
Upon entering the Local Recording mode via the keypad menu, the VCM will light the Select Key green LEDs
for 1-15 for each occupied message slot.
If a message already exists in message slot 5, it must first be erased. Press ECS Message key 8, then press Select
Key 5, (see Section Figure 11.8.3 on page 15). When the message has been erased Select Key 5's green LED will
turn off.
To record a message, press ECS Message Key 1, press Select Key 5 (this will use message slot 5 for the
recording). Select Key 5's red LED will begin flashing.
Press the push-to-talk button on the microphone and speak your message. Release the PTT button to save your
message. Select Key 5's red LED stays on until processing is completed. Select Key 5's green LED comes on
after the recording is completed.
Pressing Select Key 5 will start a playback of the recorded message.
Figure 11-7 Recording with Microphone Example
Press
Press
ECS Message
Key to enter
message slot
selection
mode
Select Key 5
to record to
this
message
slot
To Next Page
