151430-L8 Before You Begin Installation
3-14
5880 LED I/O Module
(63 max.)
5
Standby: 35 mA mA
Alarm: 200 mA mA
5883 Relay Interface
(63 max.)
5
Standby: 0 mA mA
Alarm: 220 mA (22 mA per relay) mA
VIP-50 Audio Amplifier with/
without VIP-CE4
(16 max.) Standby: 10 mA mA
Alarm: 10 mA mA
ECS-VCM Voice Control
Module
(1 max.) Standby: 70 mA mA
Alarm: 100 mA mA
ECS-SW24 Switch Expander (32 max.) Standby: 10 mA mA
Alarm: 25 mA mA
ECS-50W or ECS-125W Audio
Amplifier with/without ECS-
CE4
(16 max.) Standby: 10 mA mA
Alarm: 10 mA mA
ECS-INT-50W Internal
Amplifier
(16 max.)
Standby: 52 mA mA
Alarm @ 25V: 275 mA mA
Alarm @ 70V: 310 mA mA
ECS-RPU Remote Paging Unit (7 max.)
Standby: 70 mA mA
Alarm: 100 mA mA
ECS-RCU Remote Command
Unit (includes RA-100, RVM &
SW-24)
(7 max.)
Standby: 100 mA mA
Alarm: 150 mA mA
ECS-DUAL50W (8 max.) Standby/Alarm: 10 mA mA mA
ECS-50WBU (8 max.) Standby/Alarm: 10 mA mA mA
Notification Devices Refer to devices manual for number of devices and current rating.
IFP-RPT-FO (1 max.) Standby: 24 mA mA
IFP-RPT-UTP (1 max.) Alarm: 24 mA mA
A Total System Current
Auxiliary Devices
3
Refer to devices manual for current rating.
IPDACT-2 IP Communicator (1 max.)
Standby: 93 mA mA
Alarm: 136 mA mA
IPDACT-2UD IP
Communicator
(1 max.)
Standby: 98 mA mA
Alarm: 155 mA mA
Alarm/Standby: mA mA mA
Alarm/Standby: mA mA mA
Alarm/Standby: mA mA mA
B Auxiliary Devices Current
Notification Appliance Circuits Refer to device manual for current rating.
5495/5499 Power Supply 24 VDC
One input circuit: 15 mA
mA
Both input circuits: 30 mA
mA
Alarm: mA
mA
Alarm: mA
mA
Alarm: mA
mA
C Notification Appliances Current mA
Table 3-2: Current Draw Worksheet for SD SLC Devices
Device # of Devices Current per Device
Standby
Current
Alarm Current
To Next Page
