4. Installation

4.2. Installing CIOM-A Fieldbus Interface Module TC-FFIF01

106 Experion PKS Series A Fieldbus Interface Module User's Guide R400

Honeywell July 2010

Step Action

Align the module's circuit board with the top and bottom chassis guides.

Printed circuit

board

Bottom chassis

guide alignment

Top chassis guide

alignment
