5. Configuration
5.4. Configuring Fieldbus Components In a Control Strategy
172 Experion PKS Series A Fieldbus Interface Module User's Guide R400
Honeywell July 2010
12
This completes the procedure.
Go to the next section Creating a Control
Module for sample PID loop for more
information on configuring a Control
Strategy.
Creating Control Module for sample PID loop - Optional
Th
e following procedures are optional tutorials on creating a CM to provide the PID
control loop function for the example application shown in the previous Sample
Application figure. They provide a general reference for including fieldbus function
blocks with Experion function blocks in a control strategy. This procedure assumes that
Control Builder is running and that you have added the Control Processor (CPM)/Control
Execution Environment (CEE) block to the Project tab. Also, the following fieldbus
components have been created in the Project tab, using the previous procedures in this
section.
FIM named FIM0105
