R400 Experion PKS Series A Fieldbus Interface Module User's Guide 243
July 2010 Honeywell
6. Operation
6.1 Monitoring Fieldbus Functions Through Station
Displays
Using Station Detail displays
The Experion Server Station application includes pre-configured Detail displays for the
CIOM-A FIM, Link, device and fieldbus function blocks. These displays are the default
entries for the Point Detail Page parameter on the Server Parameters tab of the
configuration form. Once you establish communications with a fieldbus H1 link you can
begin monitoring the status of any component that has been loaded as part of a Control
Strategy to a CIOM-A FIM with points registered in the Experion Server. The Detail
displays let you quickly view the component's current state, fault status, and pertinent
configuration data.
The following figure shows a sample CIOM-A FIM Detail display for reference. The
fieldbus Detail displays do feature convenient links to related fieldbus component
displays for easy access to associated data.
