Honeywell Series A - Trk_In_D; Trk_Scale

11. Appendix B
11.1. Standard Function Block Parameters
488 Experion PKS Series A Fieldbus Interface Module User's Guide R400
Honeywell July 2010
10 Value 10 (Octet String)
11 Value 11 (Date)
12 Value 12 (Time of Day)
13 Value 13 (Time Difference)
14 Value 14 (Bit String)
15 Value 15 (Time Value)
TRK_IN_D
Classification
Record
Description
Represents the discrete input for initiation of the external
tracking function.
FF Data Type
DS-66
Range
Usage
I/Input
Length
2
Valid Views
VIEW_1, VIEW_3
Storage
Non-Volatile
Remarks
Read Only
The data type consists of the value and status of discrete
value parameters. It uses the following two elements.
1 Status
2 Value
TRK_SCALE
Classification
Record
Description
Defines the high and low scale values, engineering units
code, and number of digits to the right of the decimal point
associated with TRK_VAL.
FF Data Type
DS-68
