11. Appendix B

11.1. Standard Function Block Parameters

R400 Experion PKS Series A Fieldbus Interface Module User's Guide 449

July 2010 Honeywell

Remarks

Read Only

The Data type consists of data that describes floating point

alarms. It uses the following five elements.

1 Unacknowledged

2 Alarm State

3 Time Stamp

4 Subcode

5 Value

HI_HI_LIM

Classification

Simple Variable

Description

Defines the high high alarm limit setting in engineering

units.

FF Data Type

Float

Range

PV_SCALE, + infinity

Usage

C/Contained

Length

Valid Views

VIEW_4

Storage

Static

Remarks

Initial value is + infinity

HI_HI_PRI

Classification

Simple Variable

Description

Defines priority of the high high alarm.

FF Data Type

Unsigned 8

Range

0 to 63

Usage

C/Alert Priority

Default Chapter2
