11. Appendix B

11.1. Standard Function Block Parameters

R400 Experion PKS Series A Fieldbus Interface Module User's Guide 493

July 2010 Honeywell

3 Units Index

4 Decimal Point

XD_STATE

Classification

Simple Variable

Description

Represents index to the text describing the states of a

discrete for the value obtained from the Transducer.

FF Data Type

Unsigned 16

Range

Usage

C/Contained

Length

Valid Views

VIEW_2

Storage

Static

Remarks

Main Page

Default Chapter2
