16. Appendix G

16.1. Loading CIOM-A FIM firmware

522 Experion PKS Series A Fieldbus Interface Module User's Guide R400

Honeywell July 2010

Step Action Result

Click the OK button to acknowledge the

message prompt.

Click the Resume button in the

toolbar.

Ntools begins scanning the network for

installed components. Detected nodes

will appear under the Desktop directory.

This illustration is for example purposes

only.

Click the node icon.

If this is the first time Ntools has been

used on the system, the Settings dialog

box opens. Otherwise, see the next

Result row and skip to Step 6.
