HP xw4600 User Manual

Heading Option Description
●
Serial port
●
Parallel port
●
Front USB port
●
Rear USB port
●
Internal USB port
●
System audio
●
Network controller
●
Legacy diskette
●
Embedded Security Device
●
SATA0–5
For each device, Device Available is the default setting and allows the operating system to access
the device. Device Hidden makes the device unavailable; it is disabled by the BIOS and cannot be
enabled by the operating system. When enabled, Embedded Security Device offers these options:
●
Embedded Security Device Support
●
Enable/Disable—Turns the Trusted Platform Mechanism (TPM) on and off. If this option is
enabled, the following options become available:
◦
Power-On Authentication Support—Enables and disables an authentication feature that
requires you to enter a TPM user key password to boot the system. This feature uses
the TPM to generate and store the authentication password.
◦
Reset Authentication Credential—Resets the authentication functionality and clears all
authentication credentials.
NOTE: A setup password must be set to enable the Embedded Security Device and to access
any security features associated with the Embedded Security Device.
Network Service
Boot
Enables or disables the ability to boot to the network using the F12 key or the boot order.
System IDs Asset Tag—A 16–byte string identifying the system.
Ownership Tag—An 80–byte string identifying ownership of the system. This tag is displayed on
the screen during POST.
Universal Unique Identifier (UUID)—Can only be updated if the current chassis serial number is
invalid. (These ID numbers are normally set in the factory and are used to uniquely identify the
system.)
Keyboard—Enables you to set the keyboard locale for System ID entry.
DriveLock
Security
Allows you to select a hard drive, enable or disable DriveLock security on that drive, and set a
DriveLock password. This option appears only if your drive supports DriveLock.
CAUTION: Enabling DriveLock can render a hard drive permanently inaccessible if the master
password is lost or forgotten. No method exists to recover the password or access the data.
System Security Data Execution Prevention—Enables or disables Data Execution Prevention mode in the
processors. This mode prohibits code from running in pages that were set up as data pages, and
prevents attacks such as buffer overflows. Operating system support is required for this feature.
Virtualization Technology (VTx)—Enables Intel Virtualization Technology to increase workstation
performance.
Table 3-1 Computer Setup (F10) Utility menu descriptions (continued)
32 Chapter 3 System management ENWW

HP xw4600 Specifications

General

Tcase	72.4 °C
Bus type	FSB
Stepping	E0
Processor cache	6 MB
Processor cores	2
Processor model	E8400
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo E8000 Series
Processor socket	LGA 775 (Socket T)
Processor codename	Wolfdale
Processing Die size	107 mm²
Processor frequency	3 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	1333 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	65 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	9
Number of Processing Die Transistors	410 M
Audio system	High Definition Audio
Product type	Workstation
Motherboard chipset	Intel® X38 Express
ECC	Yes
Internal memory	2 GB
Memory clock speed	800 MHz
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	2 x 1 GB
HDD speed	7200 RPM
HDD capacity	250 GB
HDD interface	SATA
Optical drive type	DVD-RW
Graphics card	-
Networking features	Gigabit Ethernet (10/100/1000)
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power supply	475 W
Chassis type	Tower
Country of origin	China
Processor code	SLB9J
Processor ARK ID	33910
Processor package size	37.5 x 37.5 mm
On-board graphics card model	Not available

Weight and Dimensions

Depth	456 mm
Width	168 mm
Height	450 mm
Weight	19000 g
