Heading Option Description
Virtualization Technology Directed
OS Management of Embedded Security Device—Enables or disables the ability of the operating
system to control the TPM device, including turning it on and off, initializing it, and resetting it.
Reset of Embedded Security Device through OS—Enables or disables the ability of the operating
system to reset the TPM.
Setup Security
Level
Enables the administrator to selectively set the security level for each setup feature. The options
are: Setup Password and None. Browser mode must be enabled to use this option.
Power OS Power
Management
Enables or disables:
●
Runtime Power Management
●
ACPI S3 Hard Disk Reset
●
ACPI S3 PS 2 Mouse Wakeup
●
USB Wake on Device Insertion
●
Unique Sleep State Blink Rates
Hardware Power
Management
Enables or disables SATA Power Management
Thermal Enables you set the rate of the system fan when the processor is in idle.
Advanced** Power-On
Options
Allows you to set:
●
POST Mode (QuickBoot, FullBoot, or FullBoot every 1–30 days).
●
POST Messages (Enable or Disable).
●
F9 Prompt (Enable or Disable). Enabling this feature displays F9=Boot Menu during POST.
Disabling this feature prevents the text from being displayed. However, pressing the F9 key
still accesses the boot menu.
●
F10 Prompt (Enable or Disable)—Enabling this feature displays F10=Setup during POST.
Disabling this feature prevents the text from being displayed, but pressing F10 still accesses
the Setup screen.
●
F11 Prompt (Enable or Disable)—Makes the Factory Recovery option visible during POST.
Disabling this feature prevents the text from being displayed, but pressing F10 still accesses
the Setup screen. Factory Recovery Boot Support must be enabled to use this option.
●
F12 Prompt (Enable or Disable)—Enabling this feature displays F12=Network Service Boot
during POST. Disabling this feature prevents the text from being displayed but pressing F12
still forces the system to attempt booting from the network.
●
Factory Recovery Boot Support (Enable or Disable)—Recovery partition hard disk drive
(HDD) option available. Vista leaves the factory with this support in place.
●
Option ROM prompt* (Enable or Disable)—Enabling this feature causes the system to display
a message before loading options ROMs.
●
Remote Wakeup Boot Source
●
After Power Loss (On or Off)—Enabling this option directs the previous state to be the default.
●
POST Delay (in seconds) (Enable or Disable)—Enabling this feature adds a user-specified
delay to the POST process. This delay is sometimes needed for hard drives on some PCI
cards that spin up slowly (so slowly that they are not ready to boot by the time POST is
Table 3-1 Computer Setup (F10) Utility menu descriptions (continued)
ENWW Computer Setup (F10) Utility 33

HP xw4600 Specifications

General

Tcase	72.4 °C
Bus type	FSB
Stepping	E0
Processor cache	6 MB
Processor cores	2
Processor model	E8400
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo E8000 Series
Processor socket	LGA 775 (Socket T)
Processor codename	Wolfdale
Processing Die size	107 mm²
Processor frequency	3 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	1333 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	65 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	9
Number of Processing Die Transistors	410 M
Audio system	High Definition Audio
Product type	Workstation
Motherboard chipset	Intel® X38 Express
ECC	Yes
Internal memory	2 GB
Memory clock speed	800 MHz
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	2 x 1 GB
HDD speed	7200 RPM
HDD capacity	250 GB
HDD interface	SATA
Optical drive type	DVD-RW
Graphics card	-
Networking features	Gigabit Ethernet (10/100/1000)
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power supply	475 W
Chassis type	Tower
Country of origin	China
Processor code	SLB9J
Processor ARK ID	33910
Processor package size	37.5 x 37.5 mm
On-board graphics card model	Not available

Weight and Dimensions

Depth	456 mm
Width	168 mm
Height	450 mm
Weight	19000 g
