346
BGP local router ID: 2.2.2.2
Local AS number: 65009
Total number of peers: 2 Peers in established state: 2
* - Dynamically created peer
Peer AS MsgRcvd MsgSent OutQ PrefRcv Up/Down State
9::2 65009 41 43 0 1 00:29:00 Established
10::2 65008 38 38 0 2 00:27:20 Established
The output shows that Switch A and Switch B have established an EBGP connection, and Switch B
and Switch C have established an IBGP connection.
# Display IPv6 BGP routing table information on Switch A.
[SwitchA] display bgp routing-table ipv6
Total number of routes: 4
BGP local router ID is 1.1.1.1
Status codes: * - valid, > - best, d - dampened, h - history,
s - suppressed, S - stale, i - internal, e - external
Origin: i - IGP, e - EGP, ? - incomplete
* >e Network : 9:: PrefixLen : 64
NextHop : 10::1 LocPrf :
PrefVal : 0 OutLabel : NULL
MED : 0
Path/Ogn: 65009i
* > Network : 10:: PrefixLen : 64
NextHop : :: LocPrf :
PrefVal : 32768 OutLabel : NULL
MED : 0
Path/Ogn: i
* e Network : 10:: PrefixLen : 64
NextHop : 10::1 LocPrf :
PrefVal : 0 OutLabel : NULL
MED : 0
Path/Ogn: 65009i
* > Network : 50:: PrefixLen : 64
NextHop : :: LocPrf :
PrefVal : 32768 OutLabel : NULL
MED : 0
Path/Ogn: i
The output shows that Switch A has learned routing information of AS 65009.
# Display IPv6 BGP routing table information on Switch C.
[SwitchC] display bgp routing-table ipv6
