HPE FlexNetwork 5510 HI Series User Manual

370
Configuring PBR
Overview
Policy-based routing (PBR) uses user-defined policies to route packets. A policy can specify the next
hop for packets that match specific criteria such as ACLs.
The device forwards received packets using the following process:
1. The device uses PBR to forward matching packets.
2. If the packets do not match the PBR policy or the PBR-based forwarding fails, the device uses
the routing table, excluding the default route, to forward the packets.
3. If the routing table-based forwarding fails, the device uses the default route to forward packets.
PBR includes the following types:
• Local PBR—Guides the forwarding of locally generated packets, such as ICMP packets
generated by using the ping command.
• Interface PBR—Guides the forwarding of packets received on an interface.
Policy
A policy includes match criteria and actions to be taken on the matching packets. A policy can have
one or multiple nodes as follows:
• Each node is identified by a node number. A smaller node number has a higher priority.
• A node contains if-match and apply clauses. An if-match clause specifies a match criterion,
and an apply clause specifies an action.
• A node has a match mode of permit or deny.
A policy compares packets with nodes in priority order. If a packet matches the criteria on a node, it is
processed by the action on the node. Otherwise, it goes to the next node for a match. If the packet
does not match the criteria on any node, it is forwarded according to the routing table.
if-match clause
PBR supports the if-match acl clause to set an ACL match criterion. On a node, you can configure
only one if-match clause.
apply clause
PBR supports the apply next-hop clause to set next hops.
Relationship between the match mode and clauses on the node
Does a packet match
all the if-match clauses
on the node?
Match mode
Permit Deny
Yes.
• If the node is configured with
apply clauses, PBR executes the
apply clauses on the node. If the
PBR-based forwarding succeeds,
PBR does not compare the packet
with the next node.
• If the node is configured with no
apply clauses, the packet is
forwarded according to the routing
table.
The packet is forwarded according
to the routing table.
