Display MAC list statistics.
display mac-list
[
name
mac-list-name ]
Display routing policy information.
display route-policy
[
name
route-policy-name ]
Clear IPv4 prefix list statistics.
reset ip prefix-list
[ prefix-list-name ]
Clear IPv6 prefix list statistics.
[ prefix-list-name ]
Clear MAC list statistics.
[ mac-list-name ]
Routing policy configuration examples
Routing policy configuration example for IPv4 route
redistribution
Network requirements
As shown in Figure 117, Switch B exchanges routing information with Switch A by using OSPF and
with Switch C by using IS-IS.
On Switch B, enable route redistribution from IS-IS to OSPF. Use a routing policy to set the cost of
route 172.17.1.0/24 to 100 and the tag of route 172.17.2.0/24 to 20.
Figure 117 Network diagram
Configuration procedure
1. Specify IP addresses for interfaces. (Details not shown.)
2. Configure IS-IS:
# Configure Switch C.
<SwitchC> system-view
[SwitchC] isis
[SwitchC-isis-1] is-level level-2
[SwitchC-isis-1] network-entity 10.0000.0000.0001.00
[SwitchC-isis-1] quit
[SwitchC] interface vlan-interface 200
[SwitchC-Vlan-interface200] isis enable
[SwitchC-Vlan-interface200] quit
[SwitchC] interface vlan-interface 201
Vlan-int100
192.168.1.1/24
Vlan-int100
192.168.1.2/24
Vlan-int200
192.168.2.2/24
Vlan-int200
192.168.2.1/24
Vlan-int201
172.17.1.1/24
Vlan-int202
172.17.2.1/24
Vlan-int203
172.17.3.1/24
Switch A
Switch B
Switch C
OSPF
IS-IS
