503
Routing policy configuration example for IPv6 route
redistribution
Network requirements
As shown in Figure 118:
• Run RIPng on Switch A and Switch B.
• Configure three static routes on Switch A.
• On Switch A, apply a routing policy to redistribute static routes 20::/32 and 40::/32 and deny
route 30::/32.
Figure 118 Network diagram
Configuration procedure
1. Configure Switch A:
# Configure IPv6 addresses for VLAN-interface 100 and VLAN-interface 200.
<SwitchA> system-view
[SwitchA] interface vlan-interface 100
[SwitchA-Vlan-interface100] ipv6 address 10::1 32
[SwitchA-Vlan-interface100] quit
[SwitchA] interface vlan-interface 200
[SwitchA-Vlan-interface200] ipv6 address 11::1 32
[SwitchA-Vlan-interface200] quit
# Enable RIPng on VLAN-interface 100.
[SwitchA] interface vlan-interface 100
[SwitchA-Vlan-interface100] ripng 1 enable
[SwitchA-Vlan-interface100] quit
# Configure three static routes with next hop 11::2, and make sure the static routes are active.
[SwitchA] ipv6 route-static 20:: 32 11::2
[SwitchA] ipv6 route-static 30:: 32 11::2
[SwitchA] ipv6 route-static 40:: 32 11::2
# Configure a routing policy.
[SwitchA] ipv6 prefix-list a index 10 permit 30:: 32
[SwitchA] route-policy static2ripng deny node 0
[SwitchA-route-policy-static2ripng-0] if-match ipv6 address prefix-list a
[SwitchA-route-policy-static2ripng-0] quit
[SwitchA] route-policy static2ripng permit node 10
[SwitchA-route-policy-static2ripng-10] quit
# Enable RIPng and apply the routing policy to static route redistribution.
[SwitchA] ripng
[SwitchA-ripng-1] import-route static route-policy static2ripng
Switch A
Switch B
Vlan-int100
10::1/32
Vlan-int100
10::2/32
Vlan-int200
11::1/32
20::/32
30::/32
40::/32
