361
Maximum allowed prefix number: 4294967295
Threshold: 75%
Minimum time between advertisements is 15 seconds
Optional capabilities:
Multi-protocol extended capability has been enabled
Route refresh capability has been enabled
Peer preferred value: 0
IPsec profile name: policy001
Routing policy configured:
No routing policy is configured
Peer: 3::2 Local: 2.2.2.2
Type: EBGP link
BGP version 4, remote router ID 3.3.3.3
BGP current state: Established, Up for 00h05m00s
BGP current event: KATimerExpired
BGP last state: OpenConfirm
Port: Local - 24897 Remote - 179
Configured: Active Hold Time: 180 sec Keepalive Time: 60 sec
Received : Active Hold Time: 180 sec
Negotiated: Active Hold Time: 180 sec Keepalive Time: 60 sec
Peer optional capabilities:
Peer support BGP multi-protocol extended
Peer support BGP route refresh capability
Peer support BGP route AS4 capability
Address family IPv6 Unicast: advertised and received
Received: Total 8 messages, Update messages 1
Sent: Total 8 messages, Update messages 1
Maximum allowed prefix number: 4294967295
Threshold: 75%
Minimum time between advertisements is 30 seconds
Optional capabilities:
Multi-protocol extended capability has been enabled
Route refresh capability has been enabled
Peer preferred value: 0
IPsec profile name: policy002
Routing policy configured:
No routing policy is configured
IPv6 BGP FRR configuration example
Network requirements
As shown in Figure 85, configure BGP FRR so that when Link B fails, BGP uses Link A to forward
traffic.
