NO TICE
● When procuring water pipes, ensure that the water pipes covered with thermal
insulation foam can be routed through holes in the bottom or top plate. For
the hole specications, see 3.8.1 Preparing Knock-out Holes.
● The humidier water inlet pipe connects to running water or other water
supply systems, and the drainpipe connects to the drainage system.
Determine the water pipes to be connected based on whether a water pump is
congured, as described in Table 3-12.
Table 3-12 Pipe routing description
Drainage
Mode
Pipe Routing Mode Connection Method
Water pump Top See A in Figure 3-4.
Bottom See B and C in Figure 3-4.
Self-drainpipe Bottom See B and C in Figure 3-4.
A water pump drainpipe can be routed from the top or bottom. Determine the
pipe routing mode based on site conditions.
Bottom Pipe Routing
Use a
at-head screwdriver to remove the hose clamp from the pipe and take out
the hose delivered with the smart cooling product. Secure the hose to the
drainpipe using a hose clamp, as shown in Figure 3-36.
