a. Enter http://192.168.1.1 (default IP address) in the address bar of the browser
and press Enter.
b. In the login window, enter the user name and password (the default value is
provided by ISP) of the administrator and click OK.
2. Configure parameters of the voice service.
The configuration procedure is as follows:
a. Click Appliciation > Broadband Phone Configuration from the navigation
tree.
b. Create WAN Connection 3 for the VoIP service and set the parameters as follows:
Parameter Value
Bearing
service
VoIP
Enabling
status
Implement
VPI/VCI Set the VPI/VCI to the same as that configured on the devices
at the central office. In this example, set this parameter to
0/35.
VLAN mode VLAN Transparent Transmission
VLAN ID VLAN ID corresponding to the user VLAN value for voice
service flows created on the ONU. In this example, set this
parameter to 200.
802.1p Enabled
Mode Route mode
DHCP Enabled
NAT Enabled
c. Click OK.
d. Choose Appliciation > Broadband Phone Configuration from the navigation
tree. Configure the parameters as follows:
Parameter Value
Address Preferred IP address of the proxy server: 200.200.200.200
Port ID Preferred signaling port ID of the proxy server: 5060
Enabling Enabled
User number When logging in to a VoIP account, you can set the user
account to the user telephone number. In this example, set
the user telephone number to 83110001.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 11 FTTB and FTTC Solution Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1018
